P3: this parameter controls your PAS or Pedal Assist functions usually it has values from 0 to 5 P2: This means the control for your Speed sensor if you doubt that you have an issue with the speed sensor so better to check the default value in your manual. P1: This value means motor characteristics parameters which include info about voltage, frequency & how your motor will perform with every value.
#Xld brain power motor controller manual manual
Press the MIDDLE BUTTON two times to move to distance reading & Temperature.Note: the tire setting is very important as it will affect the speed readingsĮbike Trick: based on my experience with this screen try to increase these settings by two inches than your actual tire size.įor example: if you have a 24-inch tire then your idle setting should be 26 inches. Press the MIDDLE BUTTON again to move to the tire setting.Save the configuration by press the middle button.set it to the maximum speed you want based on your motor capacity.the maximum speed limits will start flashing.Setting up the main Ebike Controller configurations on KT-LCD3Īfter checking the information shows in the three screens you can now start adjusting some configurations.Īdjusting Maximum Speed Limit on your ebike The third screen will give you additional information about the maximum speed that has already been set by default and also the real-time battery voltage.
This screen still has some information from the main screen however it shows you the average speed and the odometer information.Ĭheck out this Ebike LCD Display Meter KT-LCD3 24V 36V 48V on Amazon Press the middle button one more time to move to the second information screen. Note: this trick will reset the trip counter but the odometer will still count your ebike distance & there is no simple way to reset the whole ebike distance. (see the below photo)Įbike Trick: the distance meter is a trip distance meter which you can reset by holding the up & down button at the same time while you are on the main screen, once the screen starts to flash press the middle button to save the reset. Once you turn on your ebike LCD you will see the first screen information which shows you the battery levels, PAS (Pedal Assist System), speed reading, distance, motor temperature, and motor wattages. Once you turn the screen on by pressing the middle button you will see the first screen.ġ- If you turn the screen on and directly hold the button below you will activate the walking mode where your ebike motor will start working automatically & you will see a person symbol on the screen.Ģ- Pressing & holding the up botton will turn on LCD lights. This LCD has three main screens that give you different information about your ebike, also it has a screen for advanced options where you can set up your controller & ebike setting. KT-LCD3 is one of the most popular ebike LCDs in the market & has been used by a lot of ebike riders In the below lines, I will explain the difference between the parameters of the most Popular ebike controller LCD screens. 7 Conclusion Now let’s set up your ebike controller.Īs a general rule, you can set up your ebike controller using your ebike LCD display screen.
